| Seat width |
700 |
750 |
800 |
|---|
| Width ready to go |
920 |
970 |
1,020 |
|---|
| Width folded |
310 |
|---|
| Seat depth |
460 / 500 |
|---|
| Seat height front / rear |
475 / 500 // 450 / 475 |
|---|
| Overall height |
960 |
|---|
| Back rest height |
430 |
|---|
| Arm support height |
230 - 330 |
|---|
| Length with footrests |
max. 1,140 |
|---|
| Length without footrests |
max. 880 |
|---|
| Rear wheel |
610 (24") |
|---|
| max. Client weight |
300 kg |
|---|
| Empty weight |
min. 34 kg |
|---|
Permitted overall
weight |
max. 335 kg |
|---|
| Transport weight |
27.5 |
|---|
Dimensions in mm (1 inch = 25,4 mm), Weights in kg (1 pd = 0,45 kg),
Speed in km/h (1 mph = 1,61 km/h), Tolerance ± 10 mm / 0,39 inch
The specifications are subject to constructional changes.
