| Seat width |
530 - 700 |
|---|
| Seat depth |
430 - 600 |
|---|
| Back rest height |
530 - 570 |
|---|
| Shank lenght |
370 - 510 |
|---|
| Arm support height |
170 - 280 |
|---|
Front seat height (with / without
cushion) |
460 - 560 / 530 - 630 |
|---|
| Length with footrests |
1,150 |
|---|
| Length without footrests |
850 |
|---|
| Width ready to go |
670 |
|---|
| Height without headrest |
1,020 - 1,150 |
|---|
| Transport dim. width |
710 - 760 |
|---|
| Transport dim. length |
850 |
|---|
| Transport dim. height min. |
650 |
|---|
| Front wheel size |
260 x 70 (10“) |
|---|
| Rear wheel size |
350 x 75 (14“) |
|---|
| Max. obstacle height max. |
60 |
|---|
| Turning radius |
950 |
|---|
| Reichweite mit Batterie 63 Ah (5h), 73 Ah (20h) max. 6) |
30 - 35 |
|---|
| Empty transport weight min. |
130 |
|---|
| Client weight max. |
160 - 200 |
|---|
| Permitted overall weight |
340 |
|---|
| Additional loading max. |
10 |
|---|
| Driving speeds |
6 /10 |
|---|
| Motor performance |
2 x 300 / 2 x 350 |
|---|
| Driving range max. |
35 |
|---|
| Permitted gradient |
13 % |
|---|
| Type of steering |
indirect |
|---|
| Electric lift |
300 |
|---|
| Electric tilt-in-space |
0° - +18° |
|---|
| Mechanical tilt-in-space |
0° - +10° |
|---|
| Back angle electric |
-10° - +50° |
|---|
| Back angle mechanical |
-10° - +30° |
|---|
Dimensions in mm, Weights in kg, Speed in km/h, Tolerance ± 10 mm
