Fields of Application
- For permanent and long-term care
- Very well suited for various conditions, also for severely disabled people
- For users with the ability to stand and walk independently to some degree (transfer via the stand)
- For neurological conditions
Adjustment
- Active adjustment possibilities for ideal performance
- 3 frame lengths,short, standard or long
- Seat widths from 320 - 520 mm
- Seat depths from 380 - 500 mm
- Optimal adjustment of the castor fork guarantees perfectly straight forward movement
Operation
- Easy handling and transfer
- Very stabile due to few screw fastenings and light weight
- Adjusts with little effort
- Foldable, detachable wheels
Options
- Back rest and seat with vented material
- Individual push handles
- Seat cushion
- Spoke guard
- Anti-tip wheels
- Passive lighting
- Therapy table (for indepentent users)
- Safety belt with lock
- Step tube
- Folding footrest
- Accessory net
- Xtrends articles
Folding system optimised to reduce size
Operating requires very little force
Individually adjustable chassis
Unique side guard with height-adjustable armrests that can be operated with one hand
| Seat width | 320 | 340 | 360 | 380 | 400 | 420 | 440 | 460 | 480 | 500 | 520 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| idth ready to go | 500 | 520 | 540 | 560 | 580 | 600 | 620 | 640 | 660 | 680 | 700 |
| Folded width | 280 with 0° wheel camber resp. 330 with 3° wheel camber | ||||||||||
| Seat depth | 380 / 400 / 420 / 440 / 460 / 480 / 500 | ||||||||||
| Seat height front / rear | 400 bis 540 / 370 bis 530 | ||||||||||
| Overall height | Seat height rear + back height | ||||||||||
| Back height | variable from 250 to 500 (+ 25 mm) | ||||||||||
| Armrest height | ca. 170 - 245 | ||||||||||
| Length with footrests | 880 - 1,030 (depending on the frame length, wheel size and position of the axle) | ||||||||||
| max. Client weight | 150 kg | ||||||||||
| Chair weight | min. 10.5 kg | ||||||||||
| Permitted overall weight | max. 170 kg | ||||||||||
| Transport weight | 6,5 | ||||||||||
| Rear wheel | 610 (22") 600 (24") 635 (25") 660 (26") | ||||||||||
Dimensions in mm, Weights in kg, Speed in km/h, Tolerance ± 10 mm
