Adjustment
- The backrest angle, back extension and the height of the seat and armrests are adjustable
- Adjustment of the seat width is infinitely variable via the armrests
- The seat has adjustment rails and can be rotated through 360°
Operation
- multifunctional LCD display in eleven languages
- Speed reduction in curves
- Lighting in line with the German Road Traffic Act (StVO), including
indicators, hazard and brake lights - Hand brake
- Cruise control
Options
- Very simple operation
- Smooth manual steering
- Speed control rocker switch for thumb and finger activation
- Mechanical release of the spring-loaded brake
- Self-explanatory control panel with speed pre-selection options
State-of-the-art LED technology
1,600 Watt motor
Extremely robust cassette frame
Spring-loaded comfort seating system
| Length | 1.200 |
|---|---|
| Width | 610 |
| Seat height | 420 - 480 |
| Seat depth | 410 |
| Adjustable seat width | 450 - 670 / (+) 450 - 700* |
| Back height | 450 |
| Transport height ( with folded steering column and without seat) | 600 |
| Spring-loaded seat | |
| Automatic safety brake | |
| Number of wheels | 4 |
| Steering wheel diameter | 260 |
| Drive wheel diameter | 260 |
| Ground clearance | 100 |
| Obstacle avoidance max. | 60 |
| Turning circle radius | 1.500 |
| Continuous motor power | 400 W |
| Peak motor power | 1,600 W |
| Batteries | 2x 12 V; 50 Ah / 42,5 |
| Charging device | 6 A |
| electronics | 120 A |
| Tare weight | up to 35 km |
| Permissible slopes / gap | 9° (16 %) |
| Tare weight | 93 |
| Maximum user weight | 165 |
| Maximum total weight | 260 |
| Speed | 6/10 |
* The (+) variant encompasses a maximum seat width of 700 mm
Dimensions in mm, weight in kg, wheels in inches, speeds in km/h
Dimensional tolerances of ± 10 mm
