Seat width |
380 - 650 |
Seat depth |
400 - 560 / 400 - 560 / 500 / 480 - 530 |
Back rest height |
450 - 500 / 530 - 570 / 640 / 640 |
Shank lenght |
280 - 430 / 350 - 500 / 350 - 500 / 350 - 500 |
Arm support height |
240 - 350 / 180 - 290 / 140 - 250 / 180 - 290 |
Front seat height |
460 - 520 / 530 - 590 / 580 - 640 / 610 - 670 |
Length with footrests |
1,120 |
Length without footrests |
870 |
Width ready to go |
630 - 800 |
Height without headrest |
970 - 1,140 |
Transport dim. width |
630 |
Transport dim. length |
870 |
Transport dim. height min. |
590 |
Front wheel size |
260 x 70 (10“) |
Rear wheel size |
356 x 75 (14“) |
Max. obstacle height |
70 |
Turning radius |
900 |
Permitted gradient 38 Ah (5h), 45 Ah (20h) |
25 - 30 |
Permitted gradient 63 Ah (5h), 73 Ah (20h) |
35 - 40 |
Empty transport weight min. |
108 |
Client weight max. |
160* |
Permitted overall weight |
320 |
Additional loading max. |
10 |
Driving speeds |
6 / 10 |
Motor performance W, 6/12 |
2 x 220 / 2 x 350 |
Driving range max. |
40 / 35 |
Permitted gradient |
13 % |
Type of steering |
indirect |
Electric tilt-in-space |
-2° - +33° |
Mechanical tilt-in-space |
0° - +10° |
Back angle electric |
-10° - +50° |
Back angle mechanical |
-10° - +30° |
Seat elevation electric |
300 |
Dimensions in mm, Weights in kg, Speed in km/h, Tolerance ± 10 mm
