| Seat width in mm |
440 |
|---|
| Seat depth in mm |
400 |
|---|
| Width, folded in mm |
930 |
|---|
| Back height in mm |
460 |
|---|
| Front seat height in mm |
500 |
|---|
| Total length in mm |
923 |
|---|
| Total width in mm |
570 |
|---|
| Total height (Seat height + Back height) in mm |
464 |
|---|
| Armrest height in mm |
250 |
|---|
| Permissible total height in kg |
140 |
|---|
| Max. user weight in kg |
120 |
|---|
| Max. additional load in kg |
16/17,8 |
|---|
| Speed in km/h |
6 |
|---|
| Number of wheels |
4 |
|---|
| Wheel size, front, in mm |
175 |
|---|
| Wheel sitze, rear, in mm |
216 |
|---|
| Ground clearence |
70 |
|---|
| Max. obstacle climbing ability in mm |
40 |
|---|
| Turning radius in mm |
980 |
|---|
| Motor power in W |
1,000 |
|---|
| Batteries in Ah |
12 |
|---|
| Charger in A |
2 |
|---|
| Electronics |
35 |
|---|
| Range max. in km |
12 |
|---|
| Permitted uphill/downhill gradient in per cent |
3° / 6° |
|---|
| Steering type |
indirekt |
|---|
| Control system |
Penny & Giles
VR2 24V/35 A |
|---|
Dimensions in mm, weight in kg, wheels in inches, speeds in km/h
Dimensional tolerances of ± 10 mm
