Characteristics
- New seat adjustment module (tilt module) ensures greater stability and comfort for the user
- Biomechanical solutions for the backrest, armrests and leg rests with the MYSeat system
- The new design improves product quality and reliability, as well as service times for specialist retailers
The best of the MEYRA Group in a single product:
- TA iQ Powerbase
- MYSeat System
- NETTI Seating & Positioning
- VARILITE Seating & Positioningd
Field of Use
- Extremely small turning circle for effortless manoeuvring in the tightest of spaces
- Outstanding agility indoors and outdoors for maximum flexibility in everyday life
- Six wheels ensure constant contact with the ground for excellent stability and a smooth ride
- Impressive off-road capability for greater independence across a range of terrain conditions
Efficiency
- Easy to use and maintain
- With Dahl docking station for driving a car independently
Therapeutic Benefit
- Improving functional independence in everyday life and expanding the range of movement to enable independent use of shelves, work surfaces and control panels
- Promoting social interaction on an equal footing to improve communication and participation
- Improving the ability to carry out activities of daily living (ADL) independently, and thereby social participation
- TA IQ is suitable for
- Muscular dystrophy
- Multiple sclerosis (MS)
- Cerebral palsy
- Spinal cord injuries
- Amyotrophic lateral sclerosis (ALS)
- Traumatic brain injuries
- Parkinson’s disease
- Severe rheumatoid arthritis
Options
- Belt with automatic winder
- Therapy table, swivelling
- Remote stop
- Mobile phone holder with charging adapter
- Dahl docking adapter plate
- Special controls
Electrical seat angle adjustment
With seat lift 300 mm
Unique wheel suspension DTMS
| Seat width | 380 | 405 | 430 | 455 | 480 | 505 | 530 | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Seat depth | 400 – 550 mm | |||||||||||||
| Front seat height | 385/405 / 395/415 (12-inch drive wheel / 14-inch drive wheel) | |||||||||||||
| Overall length (measured at 0° seat angle) in mm | 1190 - 1350 | |||||||||||||
| Total width in mm | 600 - 770 | |||||||||||||
| Overall height in mm | 910 - 1180 | |||||||||||||
| Permissible user weight in kg | 140 | |||||||||||||
| Permitted total weight in kg | 320 | |||||||||||||
| Transport empty weight in kg | 100 kg without battery / 160 kg with 80Ah battery | |||||||||||||
| Motor power | 2 x 350 Watt | |||||||||||||
| Speeds in km/h | 6 / 10 / 12 | |||||||||||||
| Range in km | 35 - 40 | |||||||||||||
| Obstacle height in mm | max. 80 | |||||||||||||
| Permitted inclination/slopes | 10° (18 %) | |||||||||||||
| Electrically adjustable backrest angle | 80° - 140° / 90° - 150° / 90° - 170° (Code 25 / Code 2947 / Code 2948) | |||||||||||||
| Mechanical backrest angle | 80° - 120° (Code 401) | |||||||||||||
| Seat stroke in mm | 300 | |||||||||||||
| Seat camber electric | 0° - 45° | |||||||||||||
| Minimum turning radius in mm | 700 | |||||||||||||
| Ground clearance in mm | 60 (12,5" drive wheel), 70 (14" drive wheel) | |||||||||||||
Dimensions in mm, weights in kg, wheels in inches, dimensional tolerances ± 10 mm
