| Seat width | 350 | 400 | 450 | 500 |
| Optional seat width flexibility | 2x -15 mm |
| Overall width | min. 530 / max. 680 |
| Seat depth | 425 / 450 / 475 / 500 |
| Back height | 500 mm |
| Seat height range measured to seatplate | 440 – 500 mm |
| Total height | 1.050 mm |
| Weight of wheelchair without cushions | 29 kg |
| Max. load | 135kg |
| Max. load for car transport | 135 kg |
| Tilt angle | -8° – +22° |
| Recline angle | 92° – 137° |
| Width added to seat width with standard wheels | 180 mm |
| Leg support length with standard leg support | 320 - 680 mm |
| Arm support height (from seatplate to armpad) | 265 - 355 mm |
Dimensions in mm, weights in kg, wheels in inches, dimensional tolerances ± 10 mm
