| Seat width | | | | | 400 | 450 | 500 | | | | |
| Optional seat width flexibility | 2 x -20 mm |
| Seat depth | 425 / 450 / 475 / 500 |
| Back height | 500 mm |
| Seat height range measured to seatplat | 440 - 500 mm |
| Total height | 1.050 mm |
| Total lenght with leg rests | 1.020 mm |
| Weight of wheelchair without cushions | 28 kg |
| Max. load | 135 kg |
| Max. load for car transport | 125 kg |
| Tilt angle | -5° - +20° |
| Recline angle | 88° - 135° |
| Width added to seat width with standard wheels | +180 mm |
| Leg support length with standard leg support | 320 - 680 mm |
| Arm support height (from seatplate to armpad) | 260 - 355 mm |
Dimensions in mm, weights in kg, wheels in inches, dimensional tolerances ± 10 mm
