| Seat width | 350 | 400 | 430 | 450 | 500 |
| Optional seat width flexibility | 2x +12 mm |
| Seat depth | 420 – 500 (375 – 400) mm |
| Back height | 500 – 600 mm |
| Seat height range measured to seatplat | 440 – 500 mm |
| Total height | 1.085 mm |
| Weight of wheelchair without cushions | 30 kg |
| Max. load | 135 kg |
| Max. load for car transport | 135 kg |
| Tilt angle | -5° - +20° |
| Recline angle | - |
| Width added to seat width with standard wheels | 180 mm |
| Leg support length with standard leg support | 320 – 680 mm |
| Arm support height (from seatplate to armpad) | 265 – 355 mm |
Dimensions in mm, weights in kg, wheels in inches, dimensional tolerances ± 10 mm
