| Seat width | 650 | 700 | 750 |
| Optional seat width flexibility | 2x -25 mm |
| Seat depth | 400 – 500 mm |
| Back heig | 500 – 600 mm |
| Seat height range measured to seatplate | 475 – 485 mm |
| Weight of wheelchair without cushions | 36 kg |
| Max. load | 200 kg |
| Max. load for car transport | - |
| Tilt angle | -9° - +16° |
| Recline angle | 86° – 113° |
| Width added to seat width with standard wheels | +240 mm / 12" = +210 mm |
| Leg support length with standard leg suppor | 360 – 640 mm |
| Arm support height (from seatplate to armpad) | 185 – 325 mm |
Dimensions in mm, weights in kg, wheels in inches, dimensional tolerances ± 10 mm
