| Seat width | 250 | 300 | 350 |
| Optional seat width flexibility | 0 – 70 mm |
| Seat dept | 250 – 350 (440) mm |
| Back height | 400 mm |
| Seat height range measured to seatplate | 470 (440) mm |
| Total height | 885 mm |
| Weight of wheelchair without cushions | 25 kg |
| Max. load | 75 kg |
| Max. load for car transport | 75 kg |
| Tilt angle | -3° - +35° |
| Recline angle | 90° – 125° |
| Width added to seat width with standard wheels | 155 mm |
| Leg support length with standard leg support | 220 – 320 mm |
| Arm support height (from seatplate to armpad) | 120 – 290 mm |
Dimensions in mm, weights in kg, wheels in inches, dimensional tolerances ± 10 mm
